SECTION 1 FRAME
S
E
C
T
I
O
N
1
F
R
A
M
E
TIE-DOWNS INSTALLATIONS
0257266 1532E/1932E/2033E/2046E/2646E Ref. 2/A
0257266 2658E without Arm Guards Ref. 2/A
0257265 2658E with Arm Guards Ref. 3/A
901 3760365 D-Ring A/R
902 0630485 Bolt, Carriage 3/8"-16NC x 1" (2 per Tie-Down) A/R
903 4751600 Flatwasher 3/8" (2 per Tie-Down) A/R
904 3311605 Locknut 3/8"-16NC (2 per Tie-Down) A/R
905 1702300 Decal - Tie Down (Not Shown - See Section 8 for
Location) A/R
FIGURE 1-9. FRAME MOUNTED COMPONENTS INSTALLATION (GRAVITY DOWN MACHINES)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
