SECTION 1 FRAME
.
FIGURE 1-10. BATTERY CHARGER ASSEMBLIES - SINGLE VOLTAGE
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
BATTERY CHARGER ASSEMBLIES - SINGLE VOLTAGE Ref.
Note: Charger Serial Number Nameplate located on front
of charger. First line is the charger spec and date code.
Prior to Mid-February 1996 Example: BA515 (spec) AP
(date code). First letter in the date code indicates month
(A-January/B-February/C-March/etc. with exception of let-
“I” which is not used). Second letter indicates year (S-
T-1996). After Mid-February 1996 Example: BA515 (spec)
9631 (date code). First and second digits in the date code
indicate year. Third and fourth digits indicate week of
manufacture.
0400148 BATTERY CHARGER ASSEMBLY - 60HZ/120V Ref. B
(AUSTRALIAN SPEC MACHINES)
0400145 BATTERY CHARGER ASSEMBLY - 50HZ/240V Ref. B
(EUROPEAN SINGLE VOLTAGE)
1 Transformer Options: 1
7011658 60Hz/120V Charger
7018524 50Hz/240V Charger
2 Capacitor Options: 1
7011543 60Hz/120V Charger
7011523 50Hz/240V Charger
3 7011560 Strap, Capacitor 1
4 7011576 Diode 2
5 Varistor Options: 1
Not Available 60Hz/120V Charger
7011596 50Hz/240V Charger
6 7018512 Board, Circuit 1
7018513 Harness - 8 Wire from PC Board 1
7 7011551 Controller, Transformer 1
8 7011517 Triac 1
9 7011687 Cord, DC 1
10 7018515 Cord, AC (50Hz/240V Charger Only) 1
11 7018516 Relief, Strain (50Hz/240V Charger Only) 1
12 7011528 Relief, Strain 1
13 7018514 Breaker, Circuit - AC 1
14 7011509 Breaker, Circuit - DC 1
15 7011667 Socket, AC (60Hz/120V Charger Only) 1
16 7011684 Relay, Interlock (60Hz/120V Charger Only) 1
17 7018509 Cover, Case (Not Shown) 1
