3120847 1532E/1932E/2033E/2046E/2646E/2658E 3-39
SECTION 3 SCISSOR ARMS
S
E
C
T
I
O
N
3
S
C
I
S
S
O
R
A
R
M
S
.
FIGURE 3-11. ARM GUARDS INSTALLATION - ALL 2658E BUILT S/N 51216 TO PRESENT
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
0258676 ARM GUARDS INSTALLATION - ALL 2658E BUILT S/N Ref. 1/A
51216 TO PRESENT
1 4845515 Weldment, Top Rail 2
2 0256616 Actuator Assembly (Rear) (See 101-118 for Breakdown) 1
3 0480094 Belt, Mesh - End 2
4 4845514 Weldment, Hanger - Front 1
5 0641406 Bolt 1/4”-20NC x3/4” 26
6 4711400 Flatwasher 1/4” 40
7 3311405 Locknut 1/4”-20NC 16
8 4845510 Weldment, Hanger - Side 2
9 0480092 Belt, Mesh - Side 2
10 4240033 Tie-Strap 82
11 0480093 Belt, Mesh - End 1
12 0256615 Actuator Assembly (Front) (See 101-118 for Breakdown) 1
13 3539897 Plate, End Tray 1
14 4845371 Tray, Side 2
15 4845372 Tray, End 1
16 0641608 Bolt 3/8”-16NC x 1” 8
17 4711600 Flatwasher 3/8” 16
18 3311605 Locknut 3/8”-16” 8
19 0641418 Bolt 1/4”-20NC x 1 3/4” 4
20 2080043 Fastener, Rivnut 1/4”-20NC 16
21 4845512 Weldment, Hanger - Rear Left Side 1
22 4845513 Weldment, Hanger - Rear Right Side 1
23 1120514 Cap 10
24 4420055 Tape, UHMW 6in/15cm
25 3520072 Plug, Tube 6
0256616 ACTUATOR ASSEMBLY - REAR Ref. 3
0256615 ACTUATOR ASSEMBLY - FRONT Ref. 2
101 Tube Outer Options: 1
4567060 Rear
4567062 Front
102 Tube, Inner Options: 1
4567075 Rear
4567067 Front
103 4160136 Spring, Gas 2
104 0641509 Bolt 5/16”-18NC x 1 1/8” 2
105 0100011 Loctite (Not Shown) A/R
106 4845370 Link 1
107 3340781 Pad 2
108 0641604 Bolt 3/8”-16NC x 1/2” 8
109 4751600 Flatwasher 3/8” 8
110 4761600 Lockwasher 3/8” 8
111 0641516 Bolt 5/16”-18NC x2” 1
112 4751500 Flatwasher 5/16” 4
113 3311505 Locknut 5/16”-18NC 2
