3-8 1930ES, 2030ES 2630ES, 2646ES & 3246ES 3121247
SECTION 3 SCISSOR ARMS
109 Not Used
110 3200454 1 Mount, Switch
111 to 112 Not Used
113 4191706 3 Screw M6 x 12mm
114 Not Used
115 1061036 1 Cable, Manual Descent (Not Shown)
7020218 1 T-Handle (with 1/4”-20 Threads)
70001878 1 T-Handle (with 5mm Threads)
116 3321402 1 Jam Nut (Not Shown)
117 4160078 1 Spring, Compression (Not Shown)
118 4420070 1 Tape, Anti-Skid
FIGURE 3-2. SCISSOR ARMS INSTALLATION - 1930ES (USA BUILT MACHINES S/N
0200150266 TO S/N 0200152825 & BELGIUM BUILT MACHINES S/N 1200007882 TO S/N
1200008481) (CONTINUED)
ITEM # PART NUMBER QTY. DESCRIPTION REV.
