3-4 1930ES, 2030ES 2630ES, 2646ES & 3246ES 3121247
SECTION 3 SCISSOR ARMS
115 1061036 1 Cable, Manual Descent (Not Shown)
7020218 1 T-Handle (with 1/4”-20 Threads)
70001878 1 T-Handle (with 5mm Threads)
116 3321402 1 Jam Nut 1/4”-28NF (Not Shown)
117 4160078 1 Spring, Compression (Not Shown)
118 4420070 2 Tape, Anti-Skid (Not Shown)
FIGURE 3-1. SCISSOR ARMS INSTALLATION - 1930ES (USA BUILT MACHINES S/N
0200135154 TO S/N 0200150266 & BELGIUM BUILT MACHINES S/N 1200004293 TO S/N
1200007882) (CONTINUED)
ITEM # PART NUMBER QTY. DESCRIPTION REV.
