Page 160
7-16
1930ES, 2030ES 2630ES, 2646ES & 3246ES
SECTION 7 ELECTRICAL
505
Ref.
Inverter Electrical Components (See Section 10 for other
Components)
0272876
Ref.
1930ES
B
0273070
Ref.
2030ES/2630ES
B
0273071
Ref.
2646ES/3246ES
B
505A
1061037
1
Cable, Power - DC (8Ga)
B
505B
4460648
1
Connector, Anderson (50Amp)
505C
Not Available
3ft/1m
Cable, Power - DC (8Ga)
505D
4460648
1
Connector, Anderson (50Amp)
505E
Not Available
5ft/1.5m
Cable Electrical - 14/3
505F
4460205
1
Plug, Male 110GFI
505G
Not Available
5ft/1.5m
Cable, Power
505H
4360482
1
Switch, Toggle
505J
4922912
1
Harness, Power
A
Ref.
TOOLS FOR SERVICE (NOT SHOWN)
7002821
1
Crimper, Wire
7002823
1
Extractor, Pin - Universal
4460467
A/R
Extractor, Pin #16 Gauge
4460510
A/R
Extractor, Pin #12 Gauge
7002828
1
Stripper, Wire
2901443
1
Analyzer Kit
1600244
1
Analyzer
1060633
1
Cable, Analyzer
4460321
2
Plug, Male - 4 Position
4460226
8
Socket, Female
1001137005
1
Software Cables Kit
FIGURE 7-3. ELECTRICAL COMPONENTS INSTALLATION (FOR MODEL & S/N USAGE SEE
TOP OF PARTS LIST) (CONTINUED)
ITEM #
PART NUMBER
QTY.
DESCRIPTION
REV.
