SECTION 4 PLATFORMS
S
E
C
T
I
O
N
4
P
L
A
T
F
O
R
M
S
101 PLATFORM WELDMENT OPTIONS: 1
Note: Replacement decals must be ordered sepa-
rately - See Section 8.
3510505 Platform - 26" x 48" (Prior to S/N 33712) –
3510597 Platform - 26" x 48" (S/N 33712 to Present) A/1
3510501 Platform - 26" x 60" (Prior to S/N 33712) –
3510595 Platform - 26" x 60" (S/N 33712 to Present) A/1
0252408 FOOTSWITCH INSTALLATION Ref. D
201 4360031 Footswitch Assembly 1
7000625 Block, Contact 2
202 4460422 Connector 1
203 0641408 Bolt 1/4"-20NC x 1" 3
204 3311401 Nut 1/4"-20NC 3
205 4751400 Flatwasher 1/4" 3
206 Not Used
207 4060803 Flex-Trim 2 in./5cm
OPTIONAL 110VAC RECEPTACLE BOX INSTALLA-
TION
Ref.
Optional 110VAC Receptacle Box Installation -
Model 40ic
Ref.
0254043
Optional 110VAC Receptacle Box Installation -
Model 45ic
Ref. A
301 Not Available Box, Electrical 1
302 Not Available Receptacle, Electrical 1
303 Not Available Cover, Receptacle 1
304 Not Available Connector, Strain Relief 1
305 Not Available Plug 1
306 Not Used
307 Not Available Screw, Machine #6-32NC x 3/8" 4
308 Not Available Lockwasher #6 4
309 Not Available Gasket 1
310 to 350 Not Used
351
Harness (Main Boom) Options: (See Section 7 for
Breakdown)
1
Not Available Model 40ic
4921595 Model 45ic
352
Harness (Tower Boom) Options: (See Section 7 for
Breakdown)
1
Not Available Model 40ic
4921594 Model 45ic
FIGURE 4-1. PLATFORM COMPONENTS INSTALLATION. (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
