7-2 3120853
SECTION 7 ELECTRICAL
S
E
C
T
I
O
N
7
E
L
E
C
T
R
I
C
A
L
FIGURE 7-1. ELECTRICAL DIAGRAMS AND DIAGRAM LIST.
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
Note: Items with * indicate electrical drawings
shown in this manual. All other electrical drawings
are available from JLG Service Department upon
request.
2901249/4932338 ALARM ELECTRICAL COMPONENTS (MOTION) Ref. –/–
(OPTIONAL - EURO SPEC/ STANDARD -
AUSTRALIAN SPEC)
4921425 Harness 1
0140031 Alarm 1
4392338 BEACON ELECTRICAL DIAGRAM Ref. C
DRIVE CUT-OUT ELECTRICAL DIAGRAMS Ref.
4932859/1282596 ABOVE ELEVATION (B/M ONLY) (ITALIAN SPEC) Ref. –/B
4932860/1282596
ABOVE ELEVATION TILT (B/M ONLY)
(FRENCH SPEC)
Ref. –/B
4932865/1282581 8 METER (B/M ONLY) (DUTCH & GERMAN SPEC) Ref. –/–
4932838 GROUND CONTROL BOX ELECTRICAL DIAGRAM Ref. E/5
3730099 Resistor - 20 Ohm/12Watts 1
3990010 Diode 6 Amp 12
0256524 LIGHT PANEL ELECTRICAL DIAGRAM Ref. A
4932870 PLATFORM ELECTRICAL DIAGRAM Ref. 6
2901406 PLATFORM WORKLIGHTS ELECTRICAL DIAGRAM Ref. –
4921428 Harness 1
2920140 Worklight 2
4360070 Breaker, Circuit - 15 Amp 1
1870041* STANDARD ELECTRICAL SCHEMATIC Ref. J
