SECTION 6 HYDRAULIC
FIGURE 6-8. HYDRAULIC DIAGRAM LIST
ITEM #
PART NUMBER
QTY.
DESCRIPTION
REV.
Ref
Note: Diagrams with asterisk (*) are shown in the preceding
pages. Information on diagrams not shown is available from
JLG Service/Parts Departments.
Ref
Axle Lockout Hydraulic Diagram (Machines with Oscillating
Axle)
2792367*
Ref
All Machines Built SN 0300069000 to SN 0300083332
2792648/1283387*
Ref
Machine without Tow Package SN 0300083332 to
SN 0300140000
2792367*
Ref
Machine with Tow Package SN 0300083332 to
SN 0300140000
Ref
Drive Hydraulic Diagrams:
Ref
2WD/2WS Machines
2792362*
Ref
SN 0300069000 to SN 0300083332
2792693*
Ref
SN 0300083332 to SN 0300087266
2792712*
Ref
SN 0300087266 to SN 0300140000
Ref
4WD/2WS Machines
2792363*
Ref
SN 0300069000 to SN 0300083332
2792637*
Ref
SN 0300083332 to SN 0300087266
2792711*
Ref
SN 0300087266 to SN 0300140000
2792745*
Ref
SN 0300087266 to SN 0300140000 (With Arctic Package)
Ref
4WD/4WS Machines
2792364
Ref
SN 0300069000 to SN 0300083332
2792699
Ref
SN 0300083332 to SN 0300087266
2792710
Ref
SN 0300087266 to SN 0300140000
1001106992
Ref
SN 0300133887 to SN 0300140000 (With Arctic Package)
Ref
Oil Cooler Hydraulic Schematic
Ref
Deutz Engine
1282665
Ref
SN 0300069000 to SN 0300137668
Not Required
Ref
SN 0300137668 to SN 0300140000
1283309
Ref
Ford EFI Engine
Ref
Standard Hydraulic Diagrams:
2792365*
Ref
800A (Fenner & Haldex Brand Auxiliary Pump)
1001143187*
Ref
800A (Bucher Brand Auxiliary Pump)
2792366*
Ref
800AJ (Fenner & Haldex Brand Auxiliary Pump)
1001143188*
Ref
800AJ (Bucher Brand Auxiliary Pump)
Ref
Standard Hydraulic Schematic
2792351
Ref
SN 0300069000 to SN 0300083332
2792629
Ref
SN 0300083332 to SN 0300140000
Ref
Tow Bar Hydraulic Diagram
2792591
Ref
SN 0300069000 to SN 0300083332
2792700/1283387
Ref
SN 0300083332 to SN 0300140000
