JLG 800A_AJ ANSI Parts Manual User Manual
Page 204
2-158
SECTION 2 TURNTABLE
16C
1
Voltmeter Options:
2420203
110V
7020192
220V
16D
1
Pulley Options:
3580324
110V
3580325
220V
7027887
1
Key, Woodruff
17
2820031
AR
Heatshrink (Not Shown - Located at Platform)
18
1
Decal
3251243
110V Generator
Use
3252507
220V Generator (was p/n 1702590)
19
3251102
1
Nameplate (Not Shown - Located at Platform) (was p/n
3252764)
20
3311005
2
Locknut #10-24NC
21
3311405
1
Locknut 1/4in-20NC
22
3574225
1
Plate, Pulley Mounting
23
3580312
1
Pulley, Idler
24
3580313
1
Pulley, Grooved Idler
25
3740080
1
Relay, Bosch
26
3900322
2
Screw, Shoulder
27
4060802
1
Guard, Switch (Not Shown - Located at Platform)
28
4240018
AR
Tie-Strap
29
4340738
1
Support, Idler Pulley
30
4360336
1
Switch, Toggle (Not Shown - Located at Platform)
31
4568734
1
Spacer, Tube (Idler Pulley Non-Grooved)
32
4568735
1
Spacer, Tube (Idler Pulley Grooved)
33
4711400
1
Flatwasher 1/4in Narrow
34
4711700
2
Flatwasher 7/16in Narrow
35
4740397
1
Spacer
36
4751000
2
Flatwasher #10 Wide
37
4751600
3
Flatwasher 3/8in Wide
38
4751800
1
Flatwasher 1/2in Wide
39
4891500
1
Flatwasher 5/16in Hardened
40
4891600
4
Flatwasher 3/8in Hardened
41
4892000
2
Flatwasher 5/8in Hardened
FIGURE 2-31. 2500W GENERATOR INSTALLATION - FORD MACHINES (OPTIONAL) (SN
0300077500 TO SN 0300140000) (CONTINUED)
ITEM #
PART NUMBER
QTY.
DESCRIPTION
REV.
