SECTION 6 - GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE
6-4
– JLG Lift –
3121630
Engine Data
Table 6-4. Deutz D2011L04 Specifications
Type
Liquid Cooled (Oil)
Fuel
Diesel
Oil Capacity
Cooling System
Crankcase
Total Capacity
5 Quarts (4.5 L)
11 Quarts (10.5 L) w/Filter
16 Quarts (15 L)
Idle RPM
1000
Low RPM
1800
High RPM
2600
Alternator
55 Amp, belt drive
Fuel Consumption
0.88 GPH (3.33 lph)
Battery
1000 Cold Cranking Amps, 210 minutes
Reserve Capacity, 12 VDC
Horsepower
61.6 @ 2600 RPM, full load
Table 6-5. Deutz TD 2.9 Specifications
Fuel
Ultra Low Sulfur Diesel (15 ppm)
Output
67 hp (50 kW)
Torque
173 ft.lbs. (234 Nm) @ 1800rpm
Oil Capacity (Crankcase)
2.4 Gallon (8.9 L) w/Filter
Cooling System
3.3 Gallon (12.5 L)
Low RPM
1200 ±50 rpm
High RPM
2600±50 rpm
Alternator
95 Amp
Fuel Consumption
0.65 GPH (2.48 lph)
