JANUARY 17, 2012 2 KCO-25E
 ASAP Distributor Required Stocking Parts
 Doors Are Not Returnable
IMPORTANT: When ordering parts, please provide the
model, gas type and serial number of the oven. The
identification plate is located on the left side of the
combustion compartment and, also, above the control
panel under the ledge.
ELECTRICAL COMPONENTS
Ref. Part
No. No. Description
1 16037 Indicator Light, 250V, Red, Round (Qty 1)
2 31468 Motor, 208-230V, 1 PH, 1/6 HP, 50/60 HZ
(Qty 1)
3 31469 Blower Wheel, 5-1/2" Diameter (Qty 1)
4 33801 Control, Time & Temperature
(McDonald's & Standard) (Qty 1)
18588 Probe, Temperature (Qty 1)
5 33470 Relay Kit, DPST, 25 Amp., 208/240V Coil
31558 Heat Relay, only
6 31478 Power Switch, Rocker DPST (Qty 1)
Before 1/7/99
33565 Power Switch, Rocker DPST, Black (Qty 1)
1/7/99 and after
7 31485 Switch, Proximity Door (Qty 1)
31486 Actuater, Proximity Switch (In Door) (Qty 1)
8 31471 Element Assy., 208V (Qty 1)
8 31671 Element Assy., 240V (Qty 1)
9 3574 Terminal Block, 65 Amp., 600V (Qty 1)
10 21430 Axial Fan, 34 CFM, 3" (Qty 3)
31540 Cord Set Assy., 6 Feet, 1 PH (Standard)
(Qty 1)
31664 Cord Set Assy., 6 Feet, 1 PH, Locking
(McDonald's) (Qty 1)
11 33300 Snap Disc, Hi-Limit 140/20 (Qty 1)
INFINITE CONTROLS
Ref. Part
No. No. Description
12 16037 Indicator Light, 250V, Red, Round (Qty 1)
13 18578 Controller, Temperature (Qty 1)
18588 Probe, Temperature (Qty 1)
14 18234 Potentiometer, Remote (Qty 1)
15 31479 Knob, Temperature (Qty 1)
16 31485 Switch, Proximity Switch (Qty 1)
17 31478 Power Switch, Rocker DPST (Qty 1)
18 31517 Timer, Digital Countdown (Qty 1)
19 24356 Transformer, 208/240V to 24V (Qty 1)
INTERIOR COMPONENTS
Ref. Part
No. No. Description
20 31474 Rack, Wire (15" x 11") (Chrome) (Each)
(No Rack Supports Needed)
21 31666 Interior Baffle, S/S (Qty 1)
DOOR COMPONENTS
Ref. Part
No. No. Description
22  31524 Door Assy., Solid (McDonald's) (Qty 1)
23 38062 Gasket, Solid Door (Silicone) (Qty1)
24 31530 Handle Assy., Door (Qty 1)
25 31529 Catch Assy., Door (Qty 1)
26 31532 Plate, Striker (Qty 1)
27 15932 Bearing, .627 ID x 3/4 Long (Qty 2)
28 16657 Bushing, Sleeve (Qty 2)
29 8594 Hinge Pin, Door w/ Bolts (Qty 2)
31486 Actuater, Proximity Switch (In Door) (Qty 1)
NOTE: Silicone gaskets are included in the door
assy's.
EXTERIOR COMPONENTS
Ref. Part
No. No. Description
20435 Legs, 4" (Set of 4)
30 31991 Decal, Control
(Time & Temp., Standard) (Qty 1)
30 31557 Decal, Control
(Time & Temp., McDonald's) (Qty 1)
31 31477 Decal, Control (Infinite) (Qty 1)
31516 Panel Assy., Control (Infinite) (Qty 1)
19556 Nameplate, Blodgett 4" (Qty 1)
