ULTRAMIZER PRO DSP1424P
5. APPENDIX
5.1 MIDI implementation
0,', ,PSOHPHQWDWLRQ FKDUW
)XQFWLRQ 7UDQVPLWWHG 5HFRJQL]HG 5HPDUNV
Basic
Channel Default
Changed OFF, 1 - 16
OFF, 1 - 16 OFF, 1 - 16
OFF, 1 - 16 memorized
Mode
Default
Messages
Altered 1,2,3,4
X
X 1,2,3,4
X
X
Note Number
True Voice X
X X
X
Velocity
Note ON
Note OFF X
X X
X
After Touch
Key´s
Ch´s X
X X
X
Pitch Bender X X
Control O 70 - 87 O 70 - 87 see add. Table
Progr.
Change
True # O (0-49)
1-50 O (0-49)
1-50
System Exclusive X X
System
Common
Song Pos
Song Sel
Tune X
X
X X
X
X
System
Real Time Clock
Commands X
X X
X
Aux
Messages
Local ON/OFF
All notes OFF
Active Sense
Reset X
X
X
X X
X
X
X
Notes
O = YES, X = NO
Mode 1:
OMNI ON, POLY
Mode 2: OMNI ON, MONO
Mode 3: OMNI OFF, POLY
Mode 4: OMNI OFF, MONO
Tab. 5.1: MIDI implementation chart
Parameter Name Display Range Midi Controller
Number
Controller Value Range
Max. Out Level -48 .. 0 70 0 .. 48
RMS Mode 71 0 = Peak, 1 = RMS
Stereo Width 0 .. 100 72 0 .. 100
Ultramizer Density 0 .. 100 73 0 .. 100
Ultramizer Speed 1 .. 100 74 0 .. 99
Ultramizer Range 0 .. 24 75 0 .. 24
Denoiser Threshold OF, -90 .. 0 76 0 .. 91
Denoiser Sensitivity 0..100 77 0 .. 100
Left / Right - 78 0 = coupled, 1 = L, 2 = R
Exciter Process 0 .. 100 79 0 .. 100
Exciter Tune 4 .. 12 80 0 .. 100
Super Bass Process 0 .. 100 81 0 .. 100
Super Bass Tune 50 .. 150 82 0 .. 100
Crossover 20 (Hz) .. 20 (kHz) 83 0 .. 30
Low Mute - 84 0 = On, 1 = Mute
High Mute - 85 0 = On, 1 = Mute
Store - 86 0 .. 49
In / Out - 87 0 = Out, 1 = In
Tab. 5.2: Controller functions with MIDI
