SECTION 6 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE
6-2 – JLG Lift – 3128791
6.2 OPERATING SPECIFICATIONS
Dimensional Data
Chassis
Table 6-1. Operating Specifications
Model X550AJ
Maximum work load (capacity)
Unrestricted:
Restricted:
300 lb. (136 kg)
440 lb. (200 kg)
Max. Vertical Platform Height
Unrestricted:
Restricted:
61.5 ft (18.77 m)
55.9 ft (17.06 m)
Max. Horizontal Platform Reach
Unrestricted:
Restricted:
20.0 ft (6.4 m)
15.74 ft (4.8 m)
Table 6-2. Dimensional Data
Model X550AJ
Overall Width (with platform removed) 31 in (0.77m)
Outriggers Deployed Width 9 ft 6 in x 9 ft 5 in
(2.8 m x 2.8 m)
Stowed Height 6 ft 6 in (1.98m)
Stowed Length 14 ft 8 in (4.47m)
Approach angle with Jib lowered: 21°
Departure angle 21°
Table 6-3. Chassis Data
Model X550AJ
Maximum Travel Grade w/ boom in stowed
position (gradeability) 21° (38.4%)
Maximum Travel Side Slope w/ boom in
stowed position 11° (19%)
Turning radius 0°
Maximum ground pressure per track (psi) 7 psi (0.49 kg/cm 2 )
Maximum ground pressure per outrigger 24.18 psi (1.7 kg/cm 2 )
Maximum outrigger pad load 4,720 lb. (2,141 kg)
Outrigger pad diameter 11.8 in (300 mm)
Max drive speed 0.80 mph (1.3 km/hr)
Max hydraulic system pressure 2901 psi (200 bar)
Maximum wind speed 28 mph (12.5m/s)
Maximum manual force 90 lb (400 N)
Electrical system voltage 12V
