SECTION 1 - SPECIFICATIONS
1-2 – JLG Lift – 3120749
Rated Gradeability - 2WD -30%
4WD - 40%
System Voltage - 12 Volts
Max. Hydraulic System Operating Pressure - 3000 psi
(207 bar)
Travel Speed (2WD) - 4.5 mph
Travel Speed (4WD) - 2.25 mph
Ground Bearing Pressure (450A)
12x16.5 pneu. - 46 psi (3.23 kg/cm
2
)
12x16.5 FF - 56 psi (3.93 kg/cm
2
)
33/1550x16.5 pneu. - 35 psi (2.46 kg/cm
2
)
33/1550x16.5 FF - 50 psi (3.51 kg/cm
2
)
Ground Bearing Pressure (450AJ)
12x16.5 pneu. - 48 psi (3.37 kg/cm
2
)
12x16.5 FF - 58 psi (4.07 kg/cm
2
)
33/1550x16.5 pneu. - 36 psi (2.53 kg/cm
2
)
33/1550x16.5 FF - 52 psi (3.65 kg/cm
2
)
1.5 TORQUE REQUIREMENTS
* Check swing bearing bolts for security after first 50
hours of operation and every 600 hours thereafter.
1.6 LUBRICATION
Hydraulic Oil
NOTE: Hydraulic oils must have anti-wear qualities at least
to API Service Classification GL-3, and sufficient
chemical stability for mobile hydraulic system ser-
vice. JLG Industries recommends Mobilfluid 424
hydraulic oil, which has an SAE viscosity index of
152.
NOTE: When temperatures remain consistently below 20
degrees F. (-7 degrees C.), JLG Industries recom-
mends the use of Mobil DTE11.
Aside from JLG recommendations, it is not advisable to
mix oils of different brands or types, as they may not con-
tain the same required additives or be of comparable vis-
cosities. If use of hydraulic oil other than Mobilfluid 424 is
desired, contact JLG Industries for proper recommenda-
tions.
Lubrication Specifications
Table 1-1.Torque Requirements
Description Torque Value Interval Hours
Wheel Lugs 170 ft. lbs.
(231 Nm)
150
Semi-Track
Wheel Lugs
90 ft. lbs.
(122 Nm)
150
Swing Bearing
(Dry)
220 ft. lbs.
(298 Nm)
50/600*
Swing Bearing
((Loctite)
240 ft. lbs.
(326 Nm)
50/600*
Table 1-2.Hydraulic Oil
Hydraulic System
Operating
Temperature Range
S.A.E. Viscosity
Grade
+0 to + 180 F
(-18 to +83 C)
10W
+0 to + 210 F
(-18 to +99 C)
10W-20, 10W30
+50 to + 210 F
(+10 to +99 C
20W-20
Table 1-3.Lubrication Specifications.
KEY SPECIFICATIONS
MPG Multipurpose Grease having a minimum dripping point of
350 degrees F. Excellent water resistance and adhesive
qualities; and being of extreme pressure type (Timken OK
40 pounds minimum).
EPGL Extreme Pressure Gear Lube (oil) meeting API
Service Classification GL-5 or Mil-Spec Mil-L-
2105.
HO Hydraulic Oil. API Service Classification GL-3,
SAE 10W-20, Viscosity Index 152, e.g. Kendall
Hyken 052.
EO Engine (crankcase) Oil. Gas - API SF/SG class,
MIL-L-2104. Diesel - API CC/CD class, MIL-L-
2104B/MIL-L-2104C.
