7-10 800S 860SJ 3121140
SECTION 7 ELECTRICAL
Ref GROUND CONTROL BOX COMPONENTS
301 to 320 Not Used
321 4460426 AR Connector, Strain Relief
322 4460470 1 Nut, Terminal
323 4460471 1 Locknut, Terminal
324 Not Used
325 4460526 1 Connector, Strain Relief
326 4460874 1 Connector (Natural)
327 4460875 1 Connector (Gray)
328 to 330 Not Used
331 4922666 1 Harness, Analyzer Cable 2/B
331A 4460226 4 Socket, Female (Not Shown - Located at J2)
331B 4460761 1 Connector, Female - 4 Position
4460227 4 Pin, Male
332 1 Engine Harness Assembly (See Items 401-468D for Break-
down)
4922654 Deutz Engine Machines
4922655 Ford Engine Machines
4922922 Caterpillar Engine Machines
333 4922594 1 Valve Harness Assembly 6/J
333A 4460880 7 DIN Connector
333B 4460320 2 Plug, Male - 2 Position
4460267 4 Pin, Male
333C Not Used
333D 4460834 1 Connector, Female - 2 Position
4460842 2 Terminal, Female
333E 4460871 22 Socket, Female
333F 4460225 1 Plug, Male - 6 Position
4460267 6 Pin, Male
333G 4460424 1 Connector, Female - 2 Position
4460267 2 Pin, Male
333H 4460226 1 Socket, Female
334 4922619 1 Ground Control Box Harness Assembly 6/F
3990010 2 Diode - 6 Amp (Not Shown - Located at Power Down Relay)
334A 4460418 7 Connector, Female - 6 Position
4460419 21 Socket, Female
334B 4460876 1 Connector - 35 Position (Blue)
4460871 23 Socket, Female
334C 4460866 1 Connector - 19 Pin
4460464 10 Pin, Male Deutsch 16 Ga
4460508 3 Pin, Male Deutsch 12 Ga
334D 4460878 1 Housing, Terminal - 4 Position
4460887 3 Terminal (12 Gauge)
334E 4120035 4 Base, Light
4460634 5 Terminal (16 Gauge)
4460635 3 Terminal (12 Gauge)
334F 4460873 1 Connector - 35 Position (Black)
4460871 19 Socket, Female
FIGURE 7-2. HARNESS COMPONENTS INSTALLATION (WITHOUT UGM) (PRIOR TO SN
0300085332) (CONTINUED)
ITEM # PART NUMBER QTY. DESCRIPTION REV.
