7-2 800S 860SJ 3121140
SECTION 7 ELECTRICAL
FIGURE 7-1. ELECTRICAL DIAGRAM LIST
ITEM # PART NUMBER QTY. DESCRIPTION REV.
4933243 Ref ADE SYSTEM POWER-DOWN ELECTRICAL DIAGRAM
0257157/1282571 Ref ETHER START ELECTICAL DIAGRAM
Ref GENERATOR ELECTRICAL DIAGRAM
Ref 2500W Generators (50Hz)
4933215 Ref ANSI Export Specs (110V Generators) - Caterpillar/Deutz/
Ford Engines Only (Prior to SN 0300079612)
4933216 Ref ANSI Export Specs (220V Generators) - Caterpillar/Deutz/
Ford Engines Only (Prior to SN 0300079612)
4933300 Ref ANSI Export Specs - Caterpillar/Deutz (SN 0300079612 to
SN 0300122915)
4933300 Ref ANSI Export Specs - Caterpillar/Deutz (SN 0300079612 to
SN 0300122915)
1001100027 Ref ANSI Export Specs - Caterpillar/Deutz (SN 0300122915 to
SN 0300129398)
1001112743 Ref ANSI Export Specs - Caterpillar/Deutz (SN 0300129398 to
SN 0300140000)
Ref 2500W Generators (60Hz)
4933215 Ref ANSI Specs (110V Generators) - Caterpillar/Deutz/Ford
Engines Only (Prior to SN 0300079612)
4933216 Ref ANSI Specs (220V Generators) - Caterpillar/Deutz/Ford
Engines Only (Prior to SN 0300079612)
4933300 Ref ANSI Specs - Caterpillar/Deutz/Ford Engines Only
(SN 0300079612 to SN 0300129398)
1001112588 Ref ANSI Specs - Caterpillar & Deutz Engines Only
(SN 0300129398 to SN 0300140000)
4933350 Ref ANSI Specs - GM Engines Only
Ref 7500W Generators
4933264 Ref Caterpillar & Deutz Engine Machines (Prior to
SN 0300139080)
1001112586 Ref Caterpillar & Deutz Engine Machines (SN 0300139080 to
SN 0300140000)
4933283 Ref Ford Engine Machines
4933349 Ref GM Engine Machines
Ref GLOW PLUG ELECTICAL DIAGRAM (DEUTZ MACHINES)
4933189 Ref Prior to SN 0300073336
4933217 Ref SN 0300073336 to SN 0300140000
4933193 Ref HYDRAULIC WELDER ELECTRICAL DIAGRAM
Ref LIGHTS ELECTRICAL DIAGRAM
4933231 Ref CHASSIS FLOOD LIGHTS
4933219 Ref HEAD & TAIL LIGHTS
4933249 Ref PLATFORM FLOOD LIGHTS
See Note Ref PLATFORM ELECTRICAL DIAGRAM (Note: Not Available)
