JLG 860SJ Parts Manual User Manual
Page 338
7-6
SECTION 7 ELECTRICAL
FIGURE 7-2. HARNESS COMPONENTS INSTALLATION (WITHOUT UGM) (PRIOR TO SN
ITEM #
PART NUMBER
QTY.
DESCRIPTION
REV.
Ref
HARNESS COMPONENTS INSTALLATION
Ref
NOTE: FOR MODULE IDENTIFICATION, REFER TO REVISION
LOG PAGE A.
0861416
Ref
PLATFORM CONSOLE BOX COMPONENTS
E
1 to 8
Not Used
9
1060918
7ft/2.14m
Cable, Electrical - 18/3
10 to 34
Not Used
35
4460071
1
Connector, Strain Relief
36
Not Used
37
4460428
2
Connector, Strain Relief
38
4460464
1
Pin, Male Deutsch
39
4460470
1
Nut, Terminal
40
4460471
1
Lockwasher, Terminal
41
Not Used
42
4460226
2
Socket, Female
43
Not Used
44
4922595
1
Harness, Platform Box (See Items 101-110 for Breakdown)
45
1
Harness, Upper Valve Options:
Use 4922749
Prior to SN 0300066741 (was p/n 4922620)
6/F
4922749
SN 0300066741 to SN 0300085332
2/A
45A
4460880
7
Connector, DIN
45B
4460928
8
Socket, Female
4460918
8
Socket, Female
4460926
1
Connector - 21 Position
45C
4460913
2
Lock Wedge - 3 Position
4460910
2
Connector, Female Deutsch - 3 Position
4460917
6
Pin, Male
45D
5ft/1.5m
Cable, Electrical - 18/3 Options:
1060937
Prior to SN 0300066741
1060975
SN 0300066741 to SN 0300070287
1060981
SN 0300070287 to SN 0300085332
45E
7ft/2.2m
Cable, Electrical - 18/3 Options:
1060938
Prior to SN 0300066741
1060976
SN 0300066741 to SN 0300070287
1060982
SN 0300070287 to SN 0300085332
45F
2
Connector, Strain Relief Options:
4460428
Prior to SN 0300066360
1560012
SN 0300066360 to SN 0300085332
46 to 49
Not Used
50
4460905
5
Seal, Plug
51 to 55
Not Used
56
4460225
1
Plug, Male - 6 Position
57
4460496
1
Lockwasher, Terminal
58
4460497
1
Nut, Terminal
59
4922666
1
Harness, Analyzer Cable
2/B
4460226
4
Socket, Female (Not Shown - Located at J2)
