7-16
SECTION 7 ELECTRICAL
708B cont’d
Use
100110343
1001091971, 1001100328 Installations (was
p/n 4461204)
Use
100110344
1001091972, 1001100329 Installations (was
p/n 4461207)
4461204
1001091971, 1001100328 Installations
4461207
1001091972, 1001100329 Installations
4461244
1001091973, 1001100331 Installations
4461245
1001091974, 1001100333 Installations
4461246
1001091975, 1001100337 Installations
1001141968
1001100343 & 1001141971 Kits
1001141969
1001100344 & 1001141970 Kits
708C
1
Shield, Cover Options:
4060700
0272259 Installation SN 0300085332 to
SN 0300138287 (Side Hinged Cover)
1001110873
0272259 Installation SN 0300138287 to Present (Top
Hinged Cover)
4060092
0272260 Installation
Not Required
0256202 Installation
Purchase
Receptacle
1001091973,1001091974,1001091975,1001091969,
1001091970,1001091971,1001091972,1001100331,
1001100333,1001100337,1001100326,1001100327,
1001100328 & 1001100329 Installations
3960422
1
Gasket, Cover (0272259 & 0272260 Installation Only)
708D
1
Connector, Strain Relief Options:
4460051
0272259 & 0272260 Installations
Not Required
0256202 Installation
4460968
1001091969, 1001100326, 1001091970, 1001100327
1001091971, 1001100328, 1001091972, 1001100329
Installations (Prior to SN 0300127290)
1001101191
1001091969, 1001100326, 1001091970, 1001100327
1001091971, 1001100328, 1001091972, 1001100329
Installations (SN 0300127290 to Present)
4460968
1001091973, 1001091974 & 1001091975 Installations
(Prior to SN 0300108684)
4460662
1001091973, 1001100331, 1001091974, 1001100333,
1001091975 & 1001100337 Installations (SN
0300108684 to SN 0300127290)
1001101191
1001091973, 1001100331, 1001091974, 1001100333,
1001091975 & 1001100337 Installations (SN
0300127290 to Present)
708E
1
Plug, Male Options:
4460205
0272259 Installation
4460233
0272260 Installation
Not Required
0256202 Installation
4461196
1001091969 Installation
4461199
1001091970 Installation
4461202
1001091971, 1001091973 Installations & 1001100343 &
1001141971 Kits
4461205
1001091972, 1001091974 Installations & 1001100344 &
1001141970 Kits
4461249
1001091975 Installation
FIGURE 7-2. HARNESS COMPONENTS INSTALLATION (WITHOUT UGM) (CONTINUED)
ITEM #
PART NUMBER
QTY.
DESCRIPTION
REV.
