SECTION 7 ELECTRICAL
458
1001102290
1
Connector, 2 Position (SN 0300129454 to Present)
1001102304
2
Seal (SN 0300129454 to Present)
1001102291
2
Terminal, Receptacle (SN 0300129454 to Present)
459 to 461
Not Used
462
4460464
1
Pin, Male
463
Not Used
464
4460887
1
Terminal, Molex
465 to 468
Not Used
469
Not Required
4933375
Ref
GROUND CONTROL BOX WIRING DIAGRAM
D
501
2920129
AR
Bulb, Light
502 to 504
Not Used
505
2400065
1
Fuse, 30Amp
506
2400066
1
Fuse, Holder
507 to 509
Not Used
510
4460708
2
Receptacle, Female - 15 Position
4460226
AR
Socket, Female
511
4922771
1
Harness, Angle Sensor (Boom Proximity Sensor)
1060902
9.5ft/2.9m
Cable - 18/2
511A
4460226
2
Socket, Female
511B
4460424
1
Receptacle, Female - 2 Position
512
4460894
1
Plug, Male - 6 Position)
4460892
1
Connector, Bussbar - 6 Position
513
2902443
1
Receptacle Kit
4461071
8
Socket, Female
4461072
1
Receptacle
4461073
1
Cap, Dust
4461074
1
Shell, Black
514
4922636
1
Harness, Jumper
4460226
2
Socket, Female
515 to 516
Not Required
517
4460424
1
Receptacle, Female - 2 Position (SN 0300136458 to Present)
4460226
2
Socket, Female (SN 0300136458 to Present)
Ref
STANDARD HARNESS COMPONENTS
601
2902401
1
Battery Cable Kit
B
601A
1
Cable, Battery (Red) Options:
7016813
Prior to SN 0300138238 (Starter Cable terminates at the
Start Relay)
7027027
SN 0300138238 to Present (Starter Cable terminates at the
Glow Plug Relay) (Not Shown)
601B
1
Cable, Battery (Black) Options:
7027012
Prior to SN 0300138238
7027004
SN 0300138238 to Present
601C
7016824
1
Cable (Red)
FIGURE 7-2. HARNESS COMPONENTS INSTALLATION (WITHOUT UGM) (CONTINUED)
ITEM #
PART NUMBER
QTY.
DESCRIPTION
REV.
