3121235 680S 5-9
SECTION 5 CYLINDER
FIGURE 5-3. PLATFORM LEVEL CYLINDER ASSEMBLY
ITEM # PART NUMBER QTY. DESCRIPTION REV.
1684189 Ref PLATFORM LEVEL CYLINDER ASSEMBLY E
1 0100011 AR Compound, Locking
2 0100038 AR Primer, Locking
3 0100063 AR Loctite #RC 609
4 0630535 3 Capscrew, Socket Head 1/4in-20NC x 1in
5 0961894 1 Bushing, Tapered
6 0961947 4 Bushing
7 1683059 1 Head
8 1683976 1 Rod (Note: Includes Item 6)
9 1684188 1 Barrel (Note: Includes Item 6)
10 2220883 10 Plug
11 2220885 1 Plug
12 3480267 1 Piston
13 Not Used
14 Use 2902061 1 Ring, Back-up
15 Use 2902061 2 Ring, Lock
16 Use 2902061 2 Ring, Wear
17 Use 2902061 2 Ring, Back-up
18 Use 2902061 1 O-Ring
19 Use 2902061 1 O-Ring
20 Use 2902061 1 Seal
21 Use 2902061 1 Wiper
22 Use 2902061 2 Seal
23 3760369 1 Ring, Washer
24 3931620 8 Capscrew 3/8in-16NC x 1-1/4in
25 4568402 1 Spacer, Tube
26 4641232 1 Valve, Cartridge
7011112 1 Seal Kit - 4641232 Valve
27 4640932 1 Valve, Cartridge
7011112 1 Seal Kit - 4640932 Valve
28 to 99 Not Used
— — — — — — — — — —
100 2902061 1 Seal Kit Options (Includes Items 14-22)
