SECTION 6 - GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE
6-4 – JLG Lift – 3121218
Dimensional Data Hydraulic Oil
NOTE: Hydraulic oils must have anti-wear qualities at least to API
Service Classification GL-3, and sufficient chemical stabil-
ity for mobile hydraulic system service. JLG Industries
recommends Mobilfluid 424 hydraulic oil, which has an
SAE viscosity index of 152.
Table 6-6. Dimensional Data
Machine Height (Stowed) 8 ft. 4.75 in. (2.56 m)
Machine Length (Stowed)
Over Drive Axle
27 ft. 8.125 in. (8.44 m)
Machine Width
2WS/4WD
4WS/4WD
7 ft. 11.4375 in. (242 m)
7 ft. 11.375 in. (2.42 m)
Wheelbase 8 ft. 1.50 in. (2.48 m)
Boom Elevation +60 ft. 2 13/16 in. (18.36 m)
-6 ft. 1 11/16 in. (1.87 m)
Turning Radius (Outside)
2WS/4WD
4WS/4WD
20 ft. 4.6875 in. (6.21 m)
11 ft. 2.6875 in. (3.42 m)
Turning Radius (Inside)
2WS/4WD
4WS/4WD
14 ft. 3.875 in. (5.25 m)
5 ft. 3.625 in. (1.22 m)
Table 6-7.Hydraulic Oil
Hydraulic System
Operating
Temperature Range
S.A.E. Viscosity
Grade
+0° to + 180° F
(-18° to +83° C)
10W
+0° to + 210° F
(-18° to +99° C)
10W-20, 10W30
+50° to + 210° F
(+10° to +99° C
20W-20
