SECTION 6 - GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE
3121218
– JLG Lift –
6-1
SECTION 6. GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE
6.1
INTRODUCTION
This section of the manual provides additional necessary
information to the operator for proper operation and mainte-
nance of this machine.
The maintenance portion of this section is intended as infor-
mation to assist the machine operator to perform daily main-
tenance tasks only, and does not replace the more thorough
Preventive Maintenance and Inspection Schedule included
in the Service and Maintenance Manual.
Other Publications Available:
Service and Maintenance Manual
(ANSI, CSA Spec) .................................................. 3120746
Illustrated Parts Manual (ANSI, CSA Spec) .............. 3120747
Service and Maintenance Manual (CE Spec) .......... 3120866
Illustrated Parts Manual (CE Spec)........................... 3120867
6.2
OPERATING SPECIFICATIONS
Table 6-1. Operating Specifications
Maximum Work Load (Capacity)
Unrestricted:
Restricted:
500 lb (230 kg)
1000 lb (450 kg)
Maximum Travel Grade (Gradeability)
with boom in stowed position (refer to
Figure 4-3.)
45%
Maximum Travel Grade (Side Slope)
with boom in stowed position (refer to
Figure 4-3.)
5°
Maximum Tire Load:
601S
Enhanced Hostile Environment
11,200 lbs. (5080 kg)
13,050 lbs. (5920 kg)
Ground Bearing Pressure
601S
Enhanced Hostile Environment
64 psi (4.5 kg/cm
2
)
103 psi (7.2 kg/cm
2
)
Maximum Drive Speed
4 MPH (6.44 Km/hr.)
Gross Machine Weight (Approximate)
22,510 lbs. (10,211 kg)
