SECTION 6 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE
6-2 – JLG Lift – 3121289
Reach Specifications
Ground Bearing Pressure
Pneumatic
Foam Filled
65 psi (4.57 kg/cm 2 )
65 psi (4.57 kg/cm 2 )
Maximum Drive Speed: 4.5 mph (2.0 m/s)
Maximum Hyd. Operating Pressure 4500 psi (310 bar)
Electrical System Voltage 12 volts
Table 6-1. Operating Specifications
Table 6-2. Reach Specifications
Max. Platform Height 45ft (13.72 m)
Max. Horizontal Reach-450A SII 24 ft-7.25 in. (7.50 m)
Max. Horizontal Reach-450AJ SII 24 ft-6 in (7.47 m)
Up & Over Height-450A SII 25 ft-9.5 in (7.56 m)
Up & Over Height-450AJ SII 25 ft-10 in (7.57 m)
Main Boom Up Angle 75°
Main Boom Down Angle -24°
