SECTION 6 - GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE
3121179 – JLG Lift – 6-5
Capacities
Tires
Table 6-9. Chassis Specifications - 510
Swing 357° non-continuous
Gradeability (boom in stowed posi-
tion) 40%
Max. Tire Load 7900 lb. (3583 kg)
Max. Ground Bearing Pressure
12x16.5 Tire
33/1550x16.5 - Tire
48 psi (3.37 kg/cm 2)
36 psi (2.53 kg/cm 2)
Drive Speed 4.5 mph (7.2 kph)
Axle Oscillation 4 in. (0.1 m)
Turning Radius
Inside
Outside
6.5 ft. (2.0 m)
16.4 ft. (5.0 m)
System Voltage 12 Volts
Max. Hydraulic System Operating
Pressure 4500 psi
(310 bar)
Gross Machine Weight 16,104 lbs. (7305 kg)
Table 6-10. Capacities
Fuel Tank 17 gallons (64.3 liters)
Hydraulic Tank
(machines to S/N 0300070586)
28 gallons (106 liters)
Hydraulic Tank
(S/N 0300070586 &
SN 1300000001to Present) 27 gallons (102 liters)
23.6 gal. (89 liters) to the Full line
on the sight gauge
Drive Hub 23.75 oz. (0.7 liters)
Drive Brake 2.7 oz. (0.08 liters)
Table 6-11. Tires
Size Type Pressure Weight
12x16.5 Pneumatic 90 psi (6 Bar) 128 lbs. (58 kg)
12x16.5 Foam-Filled N/A 328 lbs. (149 kg)
33/1550x16.5 Pneumatic 90 psi (6 Bar) 135 lbs. (61 kg)
33/1550x16.5 Foam-Filled N/A 395 lbs. (179 kg)
14 x 16.1 Pneumatic 40 lbs. (3 bar) 91.5 lbs. (41.5 kg)
14 x 16.1 Foam-Filled N/A 426 lbs. (193 kg)
33 x 6 x 11 Solid N/A 280 lbs. (127 kg)
