SECTION 6 - GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE
6-4 – JLG Lift – 3121179
Dimensional Data
Chassis
Table 6-6. Dimensional Data - 450
Overall Width
(12 x 16.5 tire)
(33/1550 tire)
(14 x 16.1 tire)
6 ft. 6 in. (1.98 m)
6 ft. 10 in. (2.08 m)
6 ft. 11 in. (2.11 m)
Tailswing 0
Stowed Height 7 ft. 4.4 in. (2.25 m)
Stowed Length 21 ft. 4 in. (6.5 m)
Wheel base 78 in. (1.98 m)
Track Width
(12 x 16.5 tire)
(33/1550 tire)
(14 x 16.1 tire)
65.3 in. (1.66 m)
66.3 in. (1.69 m)
66.6 in. (1.69 m)
Ground Clearance 14 in. (0.36 m)
Table 6-7. Dimensional Data - 510
Overall Width 7.4 ft. (2.26 m)
Tailswing 0
Stowed Height 7.4 ft. (2.26 m)
Stowed Length 25.1 ft. (7.68 m)
Wheel base 7.67 ft. (2.34 m)
Track Width
(12 x 16.5 tire)
(33/1550 tire)
(14 x 16.1 tire)
65.3 in. (1.66 m)
66.3 in. (1.69 m)
66.6 in. (1.69 m)
Ground Clearance 1.18 ft. (0.36 m)
Table 6-8. Chassis Specifications - 450
Swing 360° non-continuous
Rated Gradeability
2WD
4WD
30%
45%
Max. Tire Load 7900 lb. (3583 kg)
Axle Oscillation 8 in. (0.2 m)
System Voltage 12 Volts
Max. Hydraulic System Operating
Pressure 4500 psi
(310 bar)
Gross Machine Weight
450A SII
450AJ SII
14,500 lbs. (6577 kg)
16,500 lbs. (7484 kg)
