SECTION 3 - USER RESPONSIBILITIES AND MACHINE CONTROL
3-6 – JLG Lift – 3121219
7. Drive Select Switch - The drive switch provides for driv-
ing the lift. Drive is activated by selecting the drive
switch and positioning the joystick forward or back-
ward.
8. Horn - (If Equipped) - This push-button switch, when
activated, permits the operator to warn jobsite person-
nel when the machine is operating in the area.
9. Enable Trigger - Trigger on the front of the joystick must
be held in to perform joystick controlled movements.
10. Glow Plug Switch - Glow Plug Switch - A momentary
contact, push button type switch that supplies electrical
power to the engine’s glow plugs, when depressed, to
assist cold starting.
11. Platform Overload LED (does not apply to all machines)
- Illuminates when platform becomes overloaded.
When LED illuminates, immediately remove excess
weight from platform to continue safe operation.
