JLG 2658E3 Parts Manual User Manual
Page 33

3120879
1-27
S
E
C
T
I
O
N
1
F
R
A
M
E
SECTION 1 FRAME
0257372
STATIC STRAP INSTALLATION (OPTIONAL)
Ref.
4
801
Strap, Static Options:
1
Use 4240147
(Prior to S/N 0200103629) (Was P/N 4240084)
4240147
(S/N 0200103629 to Present)
802
3941406
Self Tapping
1
803
Not Used
804
4751400
Flatwasher 1/4”
1
TIE-DOWN INSTALLATIONS
Ref.
0257266
Without Arm Guards
Ref.
3
0257265
With Arm Guards
Ref.
3
901
3760365
D-Ring
A/R
902
0630485
Bolt, Carriage 3/8”-16NC x 1”
A/R
903
4751600
Flatwasher 3/8” (Prior to S/N 0200065687)
A/R
904
3311605
Locknut 3/8”-16NC
A/R
FIGURE 1-7. FRAME MOUNTED COMPONENTS INSTALLATIONS (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
