JLG 2658E3 Parts Manual User Manual
Page 147

3120879
5-21
SECTION 5
CYLINDER
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
FIGURE 5-8. STEER CYLINDER ASSEMBLY (S/N 0200105071 TO PRESENT)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
STEER CYLINDER ASSEMBLIES
Ref
1684226
1532E3/1932E3/2033E3
Ref.
B
1684227
2046E3/2646E3/2658E3
Ref.
B
Note: Original Equipment Cylinder may have been
replaced with Service Replacement Cylinder.
Identify the p/n stamp on the cylinder before
ordering parts.
Ref.
1
7017226
Locknut 1/2”-20
1
2
Use Item 100
Seal, Piston
1
3
Use Item 100
O-Ring
1
4
7016708
Piston
1
5
Not Serviced
Barrel
1
6
7023019
Rod
1
7
Use Item 100
O-Ring
1
8
Use Item 100
Ring, Back-up
1
9
Use Item 100
U-Cup
1
10
Use Item 100
Wiper
1
11
7017207
Guide
1
12
7023025
Fitting, Straight
A/R
2220472
Fitting, 90°
A/R
KIT OPTIONS:
Ref.
100
7017227
Seal Kit - Cylinder (Includes Items 2, 3, 7,8,9 and 10)
1
