JLG 2658E3 Parts Manual User Manual
Page 115
3120879
4-33
SECTION 4
PLATFORM
S
E
C
T
I
O
N
4
P
L
A
T
F
O
R
M
FIGURE 4-7. PLATFORM ACCESS INSTALLATION - FOLDDOWN HANDRAILS (MANUALLY
OPERATED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
PLATFORM ACCESS (STANDARD GATE)
INSTALLATIONS
Ref.
0258233
Standard Gate - 1532E3/1932E3/2033E3
Ref.
4
0258239
Standard Gate - 2046E3/2646E3
Ref.
9
0258244
Standard Gate - 2658E3
Ref.
10
1
Tube, Rail Options:
1
4565201
1532E3/1932E3/2033E3
4565202
2046E3/2646E3
4565203
2658E3
2
3340612
Pad
1.5ft/.5m
3
Nut Options:
A/R
3300151
Nut, Acorn 1/4”-20NC (Prior to S/N 0200098334)
2080063
Fastener, Nut 1/4”-20NC (S/N 0200098334 to
Present)
4
4751400
Flatwasher 1/4” Wide
A/R
5
0100011
Loctite #242 (Prior to S/N 0200098334)
A/R
6
3520072
Plug, Cap
A/R
7
0641418
Bolt 1/4”-20NC x 2 1/4”
A/R
8
3911428
Screw 1/4”-20NC x 1 3/4”
A/R
9
Screw Options:
A/R
3911444
Screw 1/4”-20NC x 2 3/4”
(Prior to S/N 0200098334)
2080065
Fastener, Screw 1/4”-20NC x 2 3/4”
(S/N 0200098334 to Present)
10
0641608
Bolt 3/8”-16NC x 1”
A/R
11
3311605
Locknut 3/8”-16NC
A/R
12
4751600
Flatwasher 3/8”
A/R
13
3911036
Screw #10-24NC x 2 1/4”
A/R
14
3311005
Locknut #10-24NC
A/R
15
4751000
Flatwasher #10
A/R
16
0961833
Roller A/R
17
4420055
Tape
A/R
18
3640614
Gate, Lift
1
19
Weldment, Rear Vertical Options:
A/R
Not Required
1532E3/1932E3/2033E3
0
4845741
2046E3/2646E3/2658E3
1
20
Weldment, Bottom Right Side Options:
A/R
Not Required
1532E3/1932E3/2033E3
0
4845843
2046E3/2646E3
1
4845734
2658E3
1
21
Weldment, Bottom Left Side Options:
A/R
Not Required
1532E3/1932E3/2033E3
0
4845845
2046E3/2646E3
1
4845736
2658E3
1
