SECTION 6 HYDRAULIC
FIGURE 6-5. HYDRAULIC DIAGRAM LIST
ITEM #
PART NUMBER
QTY.
DESCRIPTION
REV.
Ref
Note: Diagrams with asterisk (*) are shown in the preceding
pages. Information on diagrams not shown is available from
JLG Service/Parts Departments.
Ref
Axle Lockout Hydraulic Diagram
2792398*
Ref
Australian Spec
2792455*
Ref
CE Spec
Ref
Drive Hydraulic Diagrams:
2792385/1283084
*
Ref
2WD Machines without Tow Package
2792598/1283084
*
Ref
2WD Machines with Tow Package
2792386/1283084
*
Ref
4WD Machines
Ref
Standard Hydraulic Diagrams:
2792383/1283084
*
Ref
400S (Prior to SN 0300087630)
2792704/1283084
*
Ref
400S (SN 0300087630 to SN 0300096000)
2792384/1283084
*
Ref
460SJ (Prior to SN 0300087630)
2792705/1283084
*
Ref
460SJ (SN 0300087630 to SN 0300096000)
2792387
Ref
Standard Hydraulic Schematic
2792432
Ref
Sky Welder Hydraulic Diagram (Optional)
2792598/1283084
Ref
Tow Hydraulic Diagram
