2-42
SECTION 2 TURNTABLE
217
0902740
1
Bracket, Engine Mounting (Right Side)
218
0903063
1
Plate, Engine, Mounting
219
0962172
1
Bushing, Flanged
220
1320016
4
Clamp, Hose
221
1320022
1
Clamp, Hose
222
1
J-Clip
1320223
SN 0300077682 to SN 0300085617
1320222
SN 0300085617 to SN 0300092802
1320223
SN 0300092802 to SN 0300096000
223
1340060
1
Air Cleaner Assembly Including Filter Element
7012664
1
Element, FIlter (Not Shown)
224
1703162
2
Decal - Caution Fan Blade
225
1
Engine, Deutz - F3M2011 Options:
2000217
SN 0300077682 to SN 0300085617
2000273
SN 0300085617 to SN 0300092802
2000338
SN 0300092802 to SN 0300096000
226
2060025
1
Fan
227
AR
Fitting Options:
2180798
1
SN 0300077682 to SN 0300085617 (Fitting)
4360392
1
SN 0300077682 to SN 0300085617 (Indicator, Restriction)
2200221
1
SN 0300085617 to SN 0300096000 (Plug)
228
2220451
2
Fitting, Straight
229
2720398
2
Hose, Oil Cooler
230
2720434
1
Elbow, Rubber
231
2720449
1
Hose, Air Cleaner
232
2750532
1ft/30cm
Hose, Oil Drain
233
3200406
4
Mount, Motor
234
1
Muffler Options:
3220110
Standard
3220112
Catalytic
1320176
1
Clamp
235
3311405
8
Locknut 1/4in-20NC
236
3311505
6
Locknut 5/16in-18NC
237
3311605
20
Locknut 3/8in-16NC
238
3311805
4
Locknut 1/2in-13NC
239
3340399
2
Pad, Wear
240
3570808
1
Plate, Relay Mounting
241
3571692
1
Plate, Radiator Mounting
242
3573667
1
Support, Radiator
243
Use 3600423
1
Auxiliary Pump Assembly (was p/n 3600279) (See AUXILIARY
PUMP ASSEMBLY for Breakdown)
244
3620033
1
Radiator
245
3740067
AR
Relay Options:
2
Prior to SN 0300092802
3
SN 0300092802 to SN 0300096000
246
3960407
1
Gasket, Air Intake
247
4070497
4
Shim (11 Ga.)
248
4070498
2
Shim (16 Ga.)
249
4567495
1
Tube, Tee
FIGURE 2-11. DEUTZ ENGINE INSTALLATION (SN 0300077682 TO SN 0300096000)
(CONTINUED)
ITEM #
PART NUMBER
QTY.
DESCRIPTION
REV.
