2-44
SECTION 2 TURNTABLE
407
Use 70000916
1
Pump Fuel Supply (was p/n 7027238)
7020411
1
O-Seal Between Fuel Pump & Engine Block (Not Shown)
408
7020449
3
Gasket, Intake Manifold (Not Shown)
7020471
3
Gasket, Exhaust Manifold (Not Shown)
409
7020408
1
V-Belt
410
7027795
1
Control, EMR2 (2000273/2000338 Engine Only)
7027793
1
Connector, EMR2 Control (2000273/2000338 Engine Only)
7027796
1
Harness, EMR2 Control (2000273/2000338 Engine Only)
411
Use 7000663
1
Alternator (was p/n 7020410)
7020464
Regulator, Voltage (Not Shown)
412
7020479
1
Starter
7026608
1
Relay, Starter
413
7027769
1
Radiator Connector Kit
414
1
Sender, Oil Temperature Options (Not Shown):
7027241
2000217 Engine Only
7027791
2000273/2000338 Engine Only
415
1
Sensor, Oil Pressure Options:
7020461
2000217 Engine Only
7027790
2000273/2000338 Engine Only
416
7024565
1
Sensor, Speed (Not Shown)
70003932
1
Spacer, Sleeve (Not Shown)
417
1
Actuator, Throttle Options:
7020458
2000217 Engine Only
7027792
2000273/2000338 Engine Only
7027276
2
Spring for Actuators
418
7020459
1
Thermostat
7020460
1
Spring, Compression
419
See Note
1
Flywheel (Not Shown) (Note: Not Available for Purchase)
7024579
1
Rim, Gear (Not Shown)
420
7027245
1
Filter, Fuel
421
7027239
1
Solenoid, Start (Not Shown - Located near Throttle Actuator)
422
1
Engine Harness Options:
See Note
2000217 Engine Only (Note: Not Available for Purchase)
7027794
2000273/2000338 Engine Only
423
70000345
3
Plug, Glow (Deutz Factory Installed - Not Shown)
(2000338 Engine Only)
424
7020169
1
Pipe, Exhaust Pipe
425
1320176
1
Clamp, Exhaust
426
1
Gasket, Head Options (Not Shown):
70003479
Gasket - 1 Notch
70003480
Gasket - 2 Notch
70003481
Gasket - 3 Notch
427
70001181
1
Valve, Oil Pressure Relief (Not Shown)
FIGURE 2-11. DEUTZ ENGINE INSTALLATION (SN 0300077682 TO SN 0300096000)
(CONTINUED)
ITEM #
PART NUMBER
QTY.
DESCRIPTION
REV.
