SECTION 6 - GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE
3121213 – JLG Lift – 6-1
SECTION 6. GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE
6.1 INTRODUCTION
This section of the manual provides additional necessary
information to the operator for proper operation and mainte-
nance of this machine.
The maintenance portion of this section is intended as infor-
mation to assist the machine operator to perform daily main-
tenance tasks only, and does not replace the more thorough
Preventive Maintenance and Inspection Schedule included
in the Service and Maintenance Manual.
Other Publications Available:
Service and Maintenance Manual - ANSI ................. 3120679
Service and Maintenance Manual - CE .................... 3120817
Illustrated Parts Manual - ANSI ................................. 3120679
Illustrated Parts Manual - CE .................................... 3120812
6.2 OPERATING SPECIFICATIONS
Table 6-1. Operating Specifications
Maximum Work Load (Capacity)
Unrestricted:
Restricted:
French Spec:
500 lb (230 kg)
1000 lb. (450 kg)
585 lb (265 kg)
Maximum Travel Grade (Gradeablility) with
boom in stowed position. See Figure 4-3. 30%
Maximum Travel Grade (Side Slope) with
boom in stowed position. See Figure 4-3. 5°
Machine Height w/main boom fully
retracted and platform in normal
position. 14 ft. (4.3 m)
Machine Height w/main boom telescoped
out and platform tilted to stow at minimum-
height. 10.5 ft. (3.2 m)
Turning Radius (outside)
Axles Retracted:
Axles Extended:
24 ft. 2 in. (7.4 m)
27 ft. 2 in. (8.3 m)
Maximum Drive Speed: 2.7 mph (4.3 kph)
Gross Machine Weight (Platform Empty) 58,100 lb. (26,354 kg)
