2-30 3120719
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
6 0701417 Bolt, Metric M14 x 45mm 4
7 4751900 Flatwasher 9/16in Regular 4
8 0100011 Compound, Locking A/R
9 0681612 Bolt 3/8in-16NC x 1-1/2in (Grade 8) 3
10 4751600 Flatwasher 3/8in Regular 5
11 2860012 Key, Woodruff 1
12 3539504 Plate, Mounting 1
13 4360294 Breaker, Circuit 30 Amp 1
14 3740080 Relay, Bosch 1
15 4460023 Connector, Strain Relief 1
16 0641508 Bolt 5/16in-18NC x 1in 1
17 4751500 Flatwasher 5/16in Regular 1
18 Not Used
19 3520028 Plug, Hole 1
20 0721006 Bolt #10-24NC x 3/4in 2
21 3311005 Locknut #10-24NC 4
22 4751000 Flatwasher #10 Regular 9
23 to 24 Not Used
25 4360336 Switch, Toggle (Not Shown - Located at Platform) 1
26 4740397 Bushing (Not Shown - Located at Platform) 1
27 4060802 Guard, Switch (Not Shown - Located at Platform) 1
28 Not Used
29 2820031 Heatshrink (Not Shown - Located at Platform) 4in/10cm
30 3251102 Decal - On/Off (Not Shown - Located at Platform) 1
31 0721004 Bolt #10-24NC x 1/2in 2
32 0701015 Bolt, Metric Socket Head 10mm x 35mm 3
FIGURE 2-9. GENERATOR INSTALLATION (OPTIONAL - CONTINENTAL ENGINE MACHINES)
(CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
