544
4460800
Connector, Plug (Ford Engine Only)
29
545
4460799
Pin, Male (Ford Engine Only)
7
546 to 547
Not Used
548
4460728
Pin, Male (Ford Engine Only)
3
549
Not Used
550
2400061
Fuse (Ford Engine Only)
2
551
2400060
Holder, Fuse (Ford Engine Only)
2
552 to 553
Not Used
554
4460742
Connector, Male - 2 Position (Ford Engine Only)
1
555 to 556
Not Used
557
4460871
Socket, Female
A/R
558 to 566
Not Used
4922508
VALVE HARNESS ASSEMBLY
Ref.
4/D
601
4922508
Harness, Assembly
1
602 to 616
Not Used
617
4460880
DIN Connector
15
618
4460320
Connector, Female - 2 Position
1
619
4460267
Pin, Male
5
620
4460424
Connector, Male - 2 Position
1
621
4460268
Socket, Female
5
622
4460871
Socket, Female
28
623 to 624
Not Used
625
4460326
Connector, Male - 3 Position
1
626
4460445
Connector, Female - 3 Position
1
627 to 628
Not Used
STANDARD HARNESS COMPONENTS
Ref.
701 to 702
Not Used
703
See Note
Pump Harness (Note: Not Available for Purchase)
1
703A
7007497
Plug (Pump End)
1
703B
7007498
Plug (Engine Harness End)
1
704
See Note
Controller Harness Assembly (Lift and Swing) (Note:
Not Available for Purchase)
1
704A
7022819
Connector, Male - 9 Position
1
704B
7022820
Socket, Female
8
705
See Note
Controller Harness/Circuit Board Assembly (Drive
and Steer) (Note: Not Available for Purchase)
1
705A
7022825
Connector, Male - 9 Position
1
705B
7022820
Socket, Female
7
706
7023663
Ford Engine Harness (For replacement parts refer to
Ford engine dealer (Ford EFI Engine Machines)
1
707
See Note
Dual Fuel Shut-Off Filter Harness (Not Shown)
(Note: Not Available for Purchase)
1
7023679
Electrical Connector Kit (Includes [1] 2 Position
Connector, 2 Pins & 2 Seals)
1
FIGURE 7-14. HARNESS COMPONENTS INSTALLATION (WITH ADE SYSTEM) (S/N 0300064270 TO
S/N 0300069000) (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
