2-62
3120719
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
189
2901539
Battery Cable Kit (UL Machines Only)
1
A
189A
7016826
Cable, Battery (Red)
1
189B
7016807
Cable, Battery (Black)
1
189C
7016808
Cable (Red)
1
189D
7016827
Cable (Red)
1
189E
7016816
Cable (Black)
1
190
4460611
Terminal, Battery Jumper Post
1
191
2720058
Hose 5/16in
A/R
192
0721004
Bolt #10-24NC x 1/2in
2
193
4360294
Breaker, Circuit-30 AMP
1
194
Not Used
195
1320223
J-Clip 1/2in
4
196
3422533
Pin, Hitch
1
197
1701542
Decal - Gasoline (Not Shown - Located Near Tank)
(Not Required on UL Machines with LP)
1
198 to 199
Not Used
200
0961986
Bearing, Flange
2
201
0700819
Bolt M8 x 1.25 x 55mm
4
202
4831900
Lockwasher M8
4
203
0642010
Bolt 5/8in-11NC x 1-1/4in
1
204
4752000
Flatwasher 5/8in Regular
1
205
4711400
Flatwasher, 1/4in Thin
1
206
1060637
Cable, Lanyard
1
207
4100025
Sleeve, Fiberglass
1
208
Not Used
209
4845612
Weldment, Alternator Mount (UL Machines Only)
1
210
1641808
Bolt 1/2in-13NC x 1in
2
211
3311801
Hex Nut 1/2in-13 UNC
1
212
3790012
O-Ring (UL Machines with Dual Fuel Only)
1
213
Switch Options: (UL Machines with Dual Fuel Only)
1
4360336
S/N 0300037117 to S/N 0300049549
4360331
S/N 0300049549 to S/N 0300069000
214
4060806
Flex-Trim
16in/41cm
215
4060804
Flex-Trim
19in/49cm
216
Not Used
217
4740274
Washer, Snubbing
4
218
3570133
Bracket, Engine Mounting (Rear)
1
219
0641606
Bolt 3/8in-16NC x 3/4in
3
220
0181942
Angle, Alternator Mount (UL Machines Only)
(Not Shown Located on Opposite Side of Engine)
1
221
0701010
Bolt, Metric M10-1.5 x 20mm (UL Machines Only)
(Not Shown Located on Opposite Side of Engine)
1
222
0641624
Bolt 3/8in-16NC x 3in (UL Machines Only)
(Not Shown Located on Opposite Side of Engine)
1
223
0160020
Alternator 72 Amp (UL Machines Only)
1
224
3580260
Pulley (UL Machines Only)
1
225
3570238
Plate, Switch Mounting (UL Machines Only)
1
226
1320222
J-Clip 3/8in (Not Shown)
1
FIGURE 2-14. FORD ENGINE INSTALLATIONS - LRG425 WITH CARBURETOR (S/N 0300037117 TO
S/N 0300069000) (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
