SECTION 6 - GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE
6-8 – JLG Lift – 3121204
Tires Dimensional Data
Table 6-11. Tire Specifications
Size 14 x 17.5 14 x 17.5 14 x 17.5
Load Range G G *
Ply Rating 14 14 N/A
Tire Pressure 90 PSI (6 Bar) Foam-Filled Air-Boss
* Load Capacity - 11,800 lb. (5353 kg) - Static
Size IN355/55D 625 IN355/55D 625
Load Range* G G
Ply Rating 14 14
Tire Pressure 100 PSI (7 Bar) Foam-Filled
* Load Capacity - 12,000 lb. (5443 kg) - Static
Size 18-625
Load Range* H
Ply Rating 16
Tire Pressure 90 PSI (6 Bar)
* Load Capacity - 12,300 lb. (5579 kg) - Static
Table 6-12. Dimensional Data
Machine Height (Stowed) 8 ft. 3.75 in. (2.53 m)
Machine Length (Stowed)
600A Over Drive Axle
600AJ Over Drive Axle
26 ft. 5 in. (8.05 m)
28 ft. 11.4375 in. (8.82 m)
Machine Width
Standard
Narrow Chassis
8 ft. (2.44 m)
7 ft. (2.13 m)
Wheelbase 8 ft. 0 in. (2.44 m)
Boom Elevation - 600A +60 ft. 5 3/8 in. (18.42 m)
-11 in. (0.28 m)
Boom Elevation - 600AJ +60 ft. 6 3/4 in. (18.46 m)
-2 ft. 8 13/16 in. (0.83 m)
