SECTION 6 - GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE
3121255
– JLG Lift –
6-1
SECTION 6. GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE
6.1
INTRODUCTION
This section of the manual provides additional necessary
information to the operator for proper operation and mainte-
nance of this machine.
The maintenance portion of this section is intended as infor-
mation to assist the machine operator to perform daily main-
tenance tasks only, and does not replace the more thorough
Preventive Maintenance and Inspection Schedule included
in the Service and Maintenance Manual.
Other Publications Available:
Service and Maintenance Manual ............................ 3121256
Illustrated Parts Manual ............................................ 3121257
6.2
OPERATING SPECIFICATIONS AND
PERFORMANCE DATA
Table 6-1. Operating Specifications - Prior to S/N 0300140836
Maximum Work Load - 1100SJP (Capacity)
Unrestricted
Restricted
500 lb (230 kg)
1000 lb. (450 kg)
Maximum Work Load - 1100S (Capacity)
Unrestricted
830 lb (365 kg)
Max.Vertical Platform Height
110 ft. (33.56 m)
Max.Horizontal Platform Reach (1100SJP)
75 ft. (22.9 m)
Max.Horizontal Platform Reach (1100S)
63 ft. 11 in. (19.5 m)
JibPLUS (1100SJP Only)
Length
Horizontal Motion
Vertical Motion
8ft. (2.44m)
180° working, 244° stowed
130° (+75/-55)
Jib (1100S Only)
Length
Vertical Motion
7ft. 3.5 in. (2.22m)
130° (+75/-55)
