JLG 600SC_660SJC Parts Manual - Manual (Page 56)

2-28 3120899
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
34 0902511 Bracket, Control Module Mounting 1
35 0641818 Bolt 1/2in-13NC x 2-1/4in 2
36 3311805 Locknut 1/2in-13NC 4
37 0641610 Bolt 3/8in-16NC x 1-1/4in 21
38 3311605 Locknut 3/8in-16NC 22
39 4751600 Flatwasher 3/8in Regular 44
40 0701414 Bolt 1/4in-20NC x 3/4in 4
41 4891600 Flatwasher 3/8in Hardened 2
42 0641407 Bolt 1/4in-20NC x 7/8in 12
43 4751400 Flatwasher 1/4in Regular 20
44 3311405 Locknut 1/4in-20NC 12
45 0721005 Bolt #10-24NC x 5/8in 2
46 3311005 Locknut #10-24NC 2
47 4751000 Flatwasher #10 Regular 2
48 1320022 Clamp, Hose 6
49 2220273 Fitting, Reducer 2
50 2180536 Fitting, Straight 1
51 2220313 Fitting,90° 1
52 2750532 Hose 3/8in 6ft./1.83m
53 2220250 Fitting, Reducer 1
54 2220459 Fitting, 90° 1
55 2720271 Hose 3/16in 14ft./4.2m
56 0641812 Bolt 1/2in-13NC x 1-1/2in 2
57 0100020 Sealant, Thread A/R
58 0100011 Compound, Locking A/R
59 Not Used
60 Coupling, Rubber Intake Options: A/R
2720351 Prior to S/N 0300067975 3in./8cm
2720449 S/N 0300067975 to S/N 0300128000 1
61 0700808 Bolt, Metric M8 x 16mm 4
62 Use 2910000 Actuator Assembly (was p/n 0060033) (See Section 7 for
Breakdown) 1
63 0641508 Bolt 5/16in-18NC x 1-1/4in 3
64 0641514 Bolt 5/16in-18NC x 1-3/4in 3
65 2720434 Elbow, Rubber 1
66 4845395 Air Intake Adapter Weldment 1
67 0641510 Bolt 5/16in-18NC x 1-1/4in 3
68 3311505 Locknut 5/16in-18NC 10
69 0961986 Bushing, Flanged 2
70 2901358 Battery Cable Kit (Standard) 1
70A 7016800 Cable, Battery (Red) 1
70B 7016812 Cable, Battery (Black) 1
70C 7016802 Cable (Red) 1
70D 7016803 Cable (Red) 1
70E 7016804 Cable (Red) 1
71 4460611 Terminal, Battery Jumper Post 1
72 4360294 Breaker, Circuit - 30 Amp 1
73 1320222 J-Clip 3/8in 1
74 1320223 J-Clip 1/2in 4
FIGURE 2-9. DEUTZ ENGINE INSTALLATION (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
