3120899 5-13
SECTION 5 CYLINDER
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
.
FIGURE 5-5. MASTER CYLINDER ASSEMBLIES
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
MASTER CYLINDER ASSEMBLY Ref.
1683266 600SC Ref. C
1683263 600SJC & 660SJC Ref. E
1 Barrel Options: 1
1683267 600SC (Prior to S/N 0300052687)
(Note: Includes Item 23)
1683972 600SC (S/N 0300052687 to S/N 0300128000)
(Note: Includes Item 23)
1683264 600SJC & 660SJC (Prior to S/N 0300052687)
(Note: Includes Item 23)
1683949 600SJC & 660SJC (S/N 0300052687 to
S/N 0300128000) (Note: Item 23 not included -
Purchase Separately)
2 Rod Options: 1
1683269 600SC (Prior to S/N 0300052687)
(Note: Includes Item 23)
1683973 600SC (S/N 0300052687 to S/N 0300128000)
(Note: Includes Item 23)
1683256 600SJC & 660SJC (Prior to S/N 0300052687)
(Note: Includes Item 23)
1683962 600SJC & 660SJC (S/N 0300052687 to
S/N 0300128000) (Note: Item 23 not included -
Purchase Separately)
3 Piston Options: 1
3480210 600SC
3480188 600SJC & 660SJC
4 Head Options: 1
1683053 600SC
1683055 600SJC & 660SJC
5 Bushing, Tapered Options: 1
0961893 600SC
0961894 600SJC & 660SJC
6 4566468 Spacer, Tube 1
7 Capscrew Options: 8
3931516 600SC (5/16in-18NC x 1in)
3931620 600SJC & 660SJC (3/8in-16NC x 1-1/4in)
8 Ring, Washer Options: 1
3760368 600SC
3760369 600SJC & 660SJC
9 0100011 Compound, Locking A/R
10 0100038 Primer, Locking A/R
11 See Note Seal (Note: Use Item 30) 2
12 See Note Ring, Lock (Note: Use Item 30) 2
13 See Note O-Ring (Note: Use Item 30) 1
14 See Note Ring, Back-up (Note: Use Item 30) 1
15 See Note Ring, Wear (Note: Use Item 30) 1
16 See Note O-Ring (Note: Use Item 30) 1
17 See Note Ring, Back-up (Note: Use Item 30) 1
18 See Note Seal, Rod (Note: Use Item 30) 1
