2-4 3120899
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
18 0651406 Bolt 1/4in-28NF x 3/4in (Prior to S/N 0300071456) 3
19 Bolt Options: 2
0641420 Bolt 1/4in-20NC x 2-1/2in (Prior to S/N 0300061570 Only)
0641416 Bolt 1/4in-20NC x 2in (S/N 0300064782 to
S/N 0300128000)
20 4891400 Flatwasher 1/4in Hardened Options: A/R
Prior to S/N 0300061570 Only 2
S/N 0300064782 to S/N 0300128000 4
21 0641508 Bolt 5/16in-18NC x 1in 2
22 4891500 Flatwasher 5/16in Hardened 2
23 3311405 Locknut 1/4in-20NC 2
24 0641608 Bolt 3/8in-16NC x 1in 5
25 0140001 Horn 1
26 Not Used
27 4060918 Flex-Trim 40in/10m
28 0100011 Compound, Locking A/R
29 0902587 Bracket, Filter 1
4640931 MANUAL DESCENT VALVE ASSEMBLY (PRIOR TO
S/N 0300071456) Ref.
101 7012961 Knob 1
102 7012954 Cartridge, Needle Valve 1
7012953 Seal Kit - 7012954 Valve 1
103 7012975 Cartridge, Check Valve 1
7012540 Seal Kit - 7012975 Valve 1
104 7012976 Cartridge, Relief Valve 1
7012953 Seal Kit - 7012976 Valve 1
105 7012977 Cartridge, Pilot Valve 1
7012918 Seal Kit - 7012977 Valve 1
3600243 AUXILIARY PUMP ASSEMBLY (PRIOR TO S/N 0300070773) Ref. B
201 3600243 Auxiliary Pump Assembly 1
201A 7013755 Replacement Motor 1
7013799 Brush Kit - 7013755 1
7016744 Bolt (Mounts Motor to Mounting Bracket) 2
201B 7013711 Coupling 1
201C 7013796 Replacement Pump 1
See Note Seal Kit (Note: Not Available - Purchase Individual
Pieces.) 1
7016700 Seal, Oil 1
7016701 O-Ring 1
7016702 O-Ring 1
7022203 Bolt (Mounts Pump to Mounting Bracket) 2
FIGURE 2-1. CONTROL VALVES INSTALLATIONS (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
