SECTION 2 - TURNTABLE
90 450A Series II/450AJ Series II 3121244
FIGURE 2-10. USA BUILT MACHINES/DEUTZ ENGINE INSTALLATION
ITEM PART NUMBER QTY DESCRIPTION REV
Ref USA Built Machines use SNs 03xxxxxxxx.
Ref Belgium Built Machines use SNs 13xxxxxxxx.
Ref Romanian Built Machines use SNs E3xxxxxxxx.
Ref DEUTZ ENGINE INSTALLATIONS
0275869 Ref Machines without Arctic Package D
0275873 Ref Machines with Arctic Package E
1 0100011 AR Compound, Locking
2 0100020 AR Sealant, Pipe
4 0181727 1 Angle, Battery Hold Down
5 0400075 1 Battery (Wet)
6 0630498 2 Bolt, Battery Hold Down
7 0641410 4 Bolt 1/4in-20NC x 1-1/4in
8 0641418 2 Bolt 1/4in-20NC x 2-1/4in
9 0641610 2 Bolt 3/8in-16NC x 1-1/4in
10 0642010 1 Bolt 5/8in-11NC x 1-1/4in
11 0902443 1 Bracket, Hood Latch Mount
12 0902444 1 Bracket, Hood Support
13 1320022 AR Clamp, Fuel Line
14 1701505 1 Decal, Diesel Fuel (Not Shown)
15 1703876 1 Decal, Engine Tray Swing (USA Built Machines) (SN
0300124000 through 0300153995)
17 2180348 1 Fitting, Barbed
18 2200222 1 Plug, Pipe (Not Shown - Located on Bottom of Fuel Tank)
19 2220313 1 Fitting, Elbow Barbed
20 2221176 1 Fitting, Elbow
21 2750532 6 ft/1.83m Hose
22 3311405 6 Locknut 1/4in-20NC
23 3311605 AR Locknut 3/8in-16NC
24 3312005 1 Locknut 5/8in-11NC
25 3340399 1 Pad, Wear
26 3900254 1 Screw, Shoulder
27 4240099 AR Wire, Tie
28 4641317 1 Valve Assembly
28 7012941 2 Cartridge without Coil
28 7010543 2 Seal Kit - 7012941 Cartridge
28 7012944 2 Coil
29 4711400 8 Flatwasher 1/4in Thin
30 4751400 12 Flatwasher 1/4in Regular
31 4751600 6 Flatwasher 3/8in Regular
32 4752000 1 Flatwasher 5/8in Regular
33 4752200 2 Flatwasher 3/4in Regular
Ref Note: Arctic Package Items 34 - 45 Not Shown - Used on
Arctic Machines Only
34 1060626 1 Cord, 3 Way Extension (Located on Left Front of Engine)
35 1702943 1 Decal - Hydraulic Tank Heater (Located on bottom of Hydraulic
Oil Tank)
36 2580024 1 Heater, Battery (Located on Battery)
37 2580050 1 Heater, Hydraulic Tank (Located on bottom of Hydraulic Oil
Tank)
38 3980007 1 Seat, Battery (Located on Battery)
