SECTION 5 - CYLINDER
3121244 450A Series II/450AJ Series II 317
FIGURE 5-19. BELGIUM AND ROMANIAN BUILT MACHINES/LIFT (MAIN BOOM) CYLINDER
ITEM PART NUMBER QTY DESCRIPTION REV
Ref USA Built Machines use SNs 03xxxxxxxx.
Ref Belgium Built Machines use SNs 13xxxxxxxx.
Ref Romanian Built Machines use SNs E3xxxxxxxx.
1684244 Ref MAIN LIFT CYLINDER ASSEMBLY E
1 7026101 1 Barrel
2 7026102 1 Rod
6 0961950 4 Bearing
7 7026097 1 Piston
8 7026098 1 Head
9 7026099 1 Nut
10 70002224 1 Ring, Retaining
11 70002225 1 Seal
12 70002225 1 O-Ring
14 See Note 1 Spacer (Note: Not Available for Purchase)
19 70002225 3 Ring, Wear
20 70002225 1 Seal
21 70002225 1 O-Ring
22 70002225 1 Ring, Back-up
23 70002225 1 O-Ring
24 70002225 1 Wiper
25 4640936 1 Cartridge, Valve
25 2900770 1 Seal Kit - 4640936 Valve
26 70002225 1 O-Ring
27 70002225 1 O-Ring
29 70002219 1 Ring, Retaining
35 70002225 1 Seal Kit, Cylinder (Includes Items 11, 12, 19-24, 26 & 27)
