The following list will service fleets of machines (built to current production per date on the front cover) with repair
parts which can be installed in the field. Parts from the list should be replaced when inventory is depleted to keep
service parts stock supplied. For further information, contact your JLG dealer or the JLG Industries Parts Department.
3126020
G10-55A, G12-55A
13-1
RECOMMENDED SPARE PARTS
Part Number
Description
Qty./Machine
Boom
Tilt Cylinder Hose, (Before S/N 0160037689), (JOHN DEERE ENGINE), (see
Figure 8-24)
2
Tilt Cylinder Hose, (S/N 0160037689 & After), (JOHN DEERE ENGINE), (see
Figure 8-24)
2
Tilt Cylinder Hose, (Before S/N 0160037689), (PERKINS & CUMMINS ENGINE), (see
Figure 8-24),
2
Tilt Cylinder Hose, (S/N 0160037689 & After), (PERKINS & CUMMINS ENGINE), (see
Figure 8-24)
2
Boom Hose, (JOHN DEERE ENGINE), (see Figure 8-26)
2
Boom Hose, (JOHN DEERE & CUMMINS ENGINE), (see Figure 8-28)
2
Extend/Retract Chain, (G10-55A), (see Section 2)
4
Extend/Retract Chain, (G12-55A), (see Section 2)
4
Retract Chain, Third Section, (see Figure 2-5)
1
Bearing Pad, (G10-55A), (see Section 2)
6
Bearing Pad, (G12-55A), (see Section 2)
4
Bearing Pad, (see Section 2)
12
Bearing Pad, (see Section 2)
4
Bearing Pad, (see Section 2)
12
Bearing Pad, (see Section 2)
6
Bearing Pad, (see Section 2)
2
Bearing Pad, (Before S/N 0160038538), (see Section 2)
2
Bearing Pad, (S/N 0160038538 & After), (see Section 2)
4
Shim, 0.0598, (see Section 2)
AR
Shim, 0.0598, (see Section 2)
AR
Shim, 0.0598, (see Section 2)
AR
Shim, 0.0598, (see Section 2)
AR
Spacer, 0.0598, (see Section 2)
4
Spacer, 0.0598, (see Section 2)
22
Spacer, 0.0598, (see Section 2)
4
Spacer, 0.0598, (see Section 2)
12
Bearing Pad, Boom Hydraulics, (see Section 2)
1
Bearing Pad, Boom Hydraulics, (see Figure 8-28)
1
Quick Switch Pin, (see Figure 2-9), (Before S/N 0160037689)
1
Quick Switch Pin, (see Figure 2-9), (S/N 0160037689 & After)
1
Quick Release Pin, (see Figure 2-9), (Before S/N 0160037689)
1
Quick Release Pin, (see Figure 2-9), (S/N 0160037689 & After)
1
Engine, (JOHN DEERE)
250 Hour Filter Kit, (G10-55A), (see Figure 4-1)
1
1000 Hour Filter Kit, (G10-55A), (see Figure 4-1)
1
250 Hour Filter Kit, (G12-55A), (see Figure 4-1)
1
1000 Hour Filter Kit, (G12-55A), (see Figure 4-1)
1
Fuel Tank Cap, (Before S/N 0160020149), (see Figure 4-7)
1
Fuel Tank Cap, (S/N 0160020149 & After), (see Figure 4-7)
1
Locking Fuel Tank Cap, (Before S/N 0160020149), (see Figure 4-7)
1
Locking Fuel Tank Cap, (S/N 0160020149 thru 0160032081), (see Figure 4-7)
1
