Page 272
CAB
G10-55A, G12-55A
3126020
6-4
33
Ref
BOOM JOYSTICK WITH ADJ TILT, (see Figure 7-1 for details)
34
91563206
1
CONTROL PANEL, (Sway)
91563207
1
CONTROL PANEL, (Sway/Aux)
35
Ref
HYDRAULIC CONTROLLER, (Sway), (see Figure 7-2 for details)
Ref
HYDRAULIC CONTROLLER, (Sway/Aux), (see Figure 7-3 for details)
36
3311405
4
LOCKNUT, 1/4-20
37
Ref
HYDRAULIC CONTROLLER, (Outrigger), (see Figure 7-3 for details)
38
91563072
1
RH CONSOLE, (Before S/N 0160038105)
1001103557
1
RH CONSOLE, (S/N 0160038105 & After)
39
91563205
1
RH CONSOLE COVER
40
91561140
2
CONTROLLER BRACKET
41
91563075
1
LOWER RH CONSOLE
42
Ref
DASH HARNESS, (not shown), (see Figure 10-9 for details)
43
Ref
TRANSMISSION RELAY HARNESS, (not shown), (see Figure 10-10 for details)
44
Ref
HEATING COMPONENTS, (see Figure 6-5 for details)
45
80963101
1
WIPER SWITCH
46
1001111112
1
WINDOW WASHER FLUID TANK
47
82033997
9 ft
WASHER FLUID HOSE
48
0741404
2
FLAT HD SOCKET SCREW, 1/4-20X.5
101
1001106866
1
SEAT RISER SIDE PANEL, (open cab)
103
4761400
12
LOCKWASHER, (S/N 0160015647 thru 0160038864 excluding 0160021405 &
0160024690)
4761400
8
LOCKWASHER, (S/N 0160038865 & After including 0160021405 &
0160024690)
105
90200755
AR
GASKA-TAPE 32"
106
0630457
2
BUTTON HD SCREW, 1/4-20X1, (enclosed cab)
107
1001104327
1
SEAT RISER PANEL, (S/N 0160015647 thru 0160038864 excluding
0160021405 & 0160024690)
108
1001106849
1
AIR RETURN VENT, (enclosed cab)
Figure 6-1 Cab Assembly (Continued)
Item
Part Number
Qty.
Description
Rev.
Before S/N 0160039451 excluding
0160039394 & 0160039397
