4-10 – JLG Lift – 3124287
14 Harness, Platform Box Connector (18RS & 24RS Only) 1 A
14A 1001119020 Connector, Buss Bar 1
4460933 Plug, Male - 12 Position (Gray) 1
4460944 Socket, Female A/R
4460466 Plug, Hole A/R
14B 4460539 Plug, Male - 3 Position 1
4460944 Socket, Female 3
14C 4460536 Receptacle, Female - 3 Position 1
4460943 Pin, Male 3
4933289 EIM LOAD CELL TO PLATFORM CONTROL BOX WIRING
DIAGRAM COMPONENTS (E300A/AJ/AJP, E/M400A/AJ/AJP,
E/M450A/AJ & E/M600/A/AJ ONLY) Ref. 1/A
101 4460007 Strip, Terminal (Not Shown - Located in Platform Console Box)
(Electric Machines Only - Not Shown) 1
102 to 105 Not Used
106 4922930 EIM Load Cell To Platform Control Box Terminal Strip
Harness (Not Shown) 1 2/B
4460326 Plug, Male - 3 Position (To J2 on Platform Power Module) 1
4460226 Socket, Female 2
4460227 Pin, Male 1
4460464 Pin, Male 1
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
