RECOMMENDED SPARE PARTS
The following list will service fleets of machines (built to current production per date on the front cover) with repair
parts which can be installed in the field. Parts from the list should be replaced when inventory is depleted to keep
service parts stock supplied. For further information, contact your JLG dealer or the JLG Industries Parts Department.
91514001
G9-43A/G10-43A
13-1
SECTION 13
RECOMMENDED SPARE PARTS
Part Number
Description
Qty./Machine
BOOM ASSEMBLY
Tilt Cyl Hose, (Before S/N 0160037671), (see Figure 8-8)
2
Tilt Cyl Hose, (S/N 0160037671 thru 0160040674 excluding 0160040468 &
0160040672), (see Figure 8-8)
2
Tilt Cyl Hose, (S/N 0160040675 & After including 0160040468 & 0160040672),
(see Figure 8-8)
2
Boom Hose, (Before S/N 0160037671), (see Figure 8-8)
2
Boom Hose, (S/N 0160037671 thru 0160040674 excluding 0160040468 &
0160040672), (see Figure 8-8)
2
Boom Hose, (S/N 0160040675 & After including 0160040468 & 0160040672),
(see Figure 8-8)
1
Hose Sheave, (see Figure 2-3)
1
Bearing Pad, (see Section 2)
10
Bearing Pad, (see Section 2)
2
Bearing Pad, (see Section 2)
2
Bearing Pad, (see Section 2)
2
Bearing Pad, (see Section 2)
2
Bearing Pad, (see Section 2)
8
Bearing Pad, (see Section 2)
2
Shim, 0.0598, (see Section 2)
AR
Shim, 0.0359, (see Section 2)
AR
Shim, 0.0598, (see Section 2)
AR
Shim, 0.0359, (see Section 2)
AR
Shim, 0.0598, (see Section 2)
AR
Shim, 0.0359, (see Section 2)
AR
Shim, 0.0598, (see Section 2)
AR
Shim, 0.0359, (see Section 2)
AR
Shim, 0.0598, (see Section 2)
AR
Shim, 0.0359, (see Section 2)
AR
Shim, 0.0598, (see Section 2)
AR
Shim, 0.0359, (see Section 2)
AR
Spacer, 0.0598, (see Section 2)
10
Spacer, 0.0598, (see Section 2)
2
Spacer, 0.0598, (see Section 2)
2
Spacer, 0.0598, (see Section 2)
2
Spacer, 0.0598, (see Section 2)
2
Spacer, 0.0598, (see Section 2)
4
Spacer, 0.0598, (see Section 2)
8
Bearing Pad, Push Beam, (Before S/N 0160037671), (see Figure 2-5)
1
Bearing Pad, Push Beam, (S/N 0160037671 & After), (see Figure 2-5)
1
Quick Switch Pin, (Before S/N 160037671), (see Figure 2-8)
1
Quick Release Pin, (Before S/N 160037671), (see Figure 2-8)
1
Quick Switch Lock Pin, (S/N 0160037671 & After), (see Figure 2-8)
1
Latch, (see Section 3)
1
