OPTIONS
91514001 G9-43A/G10-43A 12-47
Figure 12-12 Auxiliary Electrics Assembly (Continued)
PY3010
16
17
13
14
18
16
17
12 9
15
10
11
8
9
9
MAST
SIDESHIFT
GND B5
SWING
EXTRA
NO CONN.
WIRE
DESIGNATION
BLACK
RED
YELLOW
BLUE
ORANGE
NO CONN.
WIRE
COLOR
A
B
C
D
E
F
CONN. BODY
LOC. LETTER
WIRE CHART
6 CONTACT SOCKET (ON BOOM HEAD)
VIEWED FROM WIRE
CONNECTION END
GROUND(YELLOW)
"TM" EXTRA (ORANGE)
"A" OPEN
"LT" SIDE SHIFT (RED) "RT" SWING (BLUE)
"S" MAST (BLACK)
VIEW D-D
VIEW E-E
E
D
D
E
NOTE: ADD LOCTITE ® 242 TM (0100011) ON ALL BOLT THREADS.
USE LOCTITE ® 545 TM (0100075) ON TUBE FITTINGS.
S/N 0160037671 & After
