SECTION 1 - SPECIFICATIONS
3120829
– JLG Sizzor –
1-1
SECTION 1. SPECIFICATIONS
1.1
CAPACITIES
Hydraulic Oil Tank
Approximately 138.17 liters (36.5 U.S. gallons) w/10% air
space.
Hydraulic System (Including Tank)
Approximately 166.56 liters (44 U.S. gallons).
Fuel Tank
Approximately 56.8 liters (15 U.S. gallons)
Engine Crankcase
Gasoline Engine
3.2 liters (3.4 quarts) w/filter
2.7 liters (2.9 quarts) w/o filter
Diesel Engine
6.0 liters (6.34 quarts) w/filter
5.5 liters (5.8 quarts) w/o filter
Coolant Capacity (Gasoline Engine)
13.2 liters (3.5 U.S. gallons)
1.2
COMPONENT DATA
Gasoline Engine
Displacement - 4.5 liter
Manufacturer/Model - Ford LRG-425
Oil Capacity
4.3 liters (4.5 quarts) w/ filter
3.8 liters (4.0 quarts) w/o filter
Low RPM - 750
Mid RPM - 2200
High RPM - 3000
Alternator - 55 Amp external
Battery - 85 Amphour, 550 Cold Cranking Amps
Fuel Consumption
Low RPM - 6.7 lph (1.8 gph)
High RPM - 11.4 lph (3.0 gph)
Horsepower - 70 @ 2800 RPM
Coolant Capacity - 13.2 liters (3.5 U.S. gallons)
Diesel Engine
Manufacturer/Model - Deutz F3L-1011
Oil Capacity
6.0 liters (6.34 quarts) w/filter
5.5 liters (5.8 quarts) w/o filter
Mid RPM - 2000
High RPM - 3000
Alternator - 60 Amphour
Battery - 60 Amphour, 1000 Cold Cranking Amps
Fuel Consumption
Low RPM - 7.19 lph (1.9 gph)
High RPM - 9.46 lph (2.5 gph)
Horsepower - 42 @ 3000 RPM
Drive/Steer System
Tires 400RTS
Standard - 31 - 15.5 x 15 NHS, 8 ply, pneumatic, inflate to
2.4 bar (35 PSI)
Optional - 12 - 16.5 NHS, 6 ply, foam filled
Tires 500RTS
Standard - 12 x 16.5 NHS, 8 ply, pneumatic, inflate to 3.1
bar (45 PSI)
Optional - 31 - 15.5 x 15 NHS, 8 ply, pneumatic, inflate to
2.4 bar (35 PSI)
Optional - 12 - 16.5 NHS, 6 ply, foam filled
Steer System
Toe-In - Adjust to 6.4 mm (1/4 in) overall
Drive Motors/Hubs/Brakes
Drive Motor - 6.3 cm
3
(2.48 in.
3
) displacement
Drive Hub (2WD Gasoline and Diesel Engine - Rear) - Hub
ratio 35:1
Drive Hub (4WD Rear) - Hub ratio 24:1
Drive Hub/Brake (4WD Front) - Hub ratio 24:1; brake -
spring applied, hydraulic release, release pressure - 11
bar (160 psi) initial, 13 bar (190 psi) full
Drive Brake (2WD/4WD Rear) - Spring applied, hydraulic
release, release pressure - 10 bar (150 psi) initial, 12 bar
(170 psi) full
